Uni-Direction Push-Button Switches >> WQP-PBS-62H03-G14-3

Product Name:	WQP-PBS-62H03-G14-3
Item no.:	H03-G14-3
Demension:
Product Class:	Uni-Direction Push-Button Switches

Product Description

Temperature	-25~55℃
Rated Load	DC 30V 1A
Contact resistance	≤0.02Ω
Insulation resistance	≥500MΩ
Withstand voltage	AC 800V(50Hz)/Min
Insertion and Extraction Force	2-8N
Life	100,000 Times

UpdateTime：2010-06-03 【Print】【Close】
